Li-ion Series
TY-HES150
High-Voltage Energy Storage Lithium-ion Battery.
Lithium energy systems
TY-HES150
High-Voltage Energy Storage Lithium-ion Battery.
SeriesLi-ion Series
Material CategoryLithium Iron Phosphate(LFP)
Rated Voltage204.8V-768V
Rated Capacity150Ah
Rated Energy30.72KWh-115.2KWh
Maximum Continuous Discharge Current120A
Supply supportOEM/ODM inquiry
Application areas
Share the operating duty and environment for application matching.
Your request, this model and the current page link go directly to Song Yang.
Technical information
Product characteristics and family data
The detailed table may cover the wider series. The model-specific facts extracted above should be confirmed against the latest approved datasheet when ordering.
Swipe or scroll horizontally to view all columns.
| Specifications | TY-HES150 | ||
|---|---|---|---|
| Material Category | Lithium Iron Phosphate (LFP) | standard Charging Current | 60A |
| Rated Voltage | 204.8V-768V | Maximum Charging Current | 60A |
| Rated Capacity | 150Ah | Operating Temperature Range | 0-55°C |
| Rated Energy | 30.72KWh-115.2KWh | Cooling Method | Natural cooling |
| Series&Parallel Connection Mode | 1P/16S-240S | Protection Grade | ip20 |
| standard Discharge Current | 120A | Communication Mode | can/wifi/rs485 |
| Maximum Continuous Discharge Current | 120A | Single pack Dimensions | 675*444*183 (mm) |
| Allowable Pulse Discharge Current | 120A | Typical System Dimensions | 675*444*1195(mm) |
